Airtac SCLB Rear Lock-Type Cylinder SCLB40X600
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB40X600 Locking Cylinder Specifications
- Model: SCLB40X600
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 40mm
- Stroke: 600mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥250N (at 0.5 MPa)
- Lock release pressure: 0.15–1.0 MPa
- Ambient temperature: -10℃ to 70℃
- Mounting type: Front flange (ISO 15552 standard)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Seal material: NBR + PU combination
- Port size: G1/8 (M5 optional)
- Rod thread: M16×1.5
- Weight: ~3.8kg (excluding accessories)
- Dimensions: 762mm(L) × 62mm(W) × 62mm(H) (extended length)
- Retracted length: 162mm
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54 (standard), IP67 (optional)
Heavy-duty locking cylinder featuring fail-safe position retention capability. The dual-piston locking mechanism ensures mid-stroke position holding even during sudden air pressure loss. Precision ground rod with hard chrome plating (3-5μm thickness) resists side loads up to 150N. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Vertical load holding in automated assembly lines
- Safety position locking in material handling systems
- Precision fixturing for CNC machining centers
- Elevation control in solar panel tracking systems
- Emergency stop mechanisms in press machinery
Installation note:
Locking function requires separate 0.3-0.6 MPa control circuit.
Allow minimum 50mm clearance around cylinder body for heat dissipation.
Lubricate through air supply (1 drop/3m³) using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | SCLB40X600 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 600mm |
| Lock Position | Rear Cover with Lock Type |
