Airtac SCLB Rear Lock-Type Cylinder SCLB50X100
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X100 Locking Cylinder Specifications
- Model: SCLB50X100
- Type: Double-acting cylinder with mechanical lock
- Bore size: 50mm
- Stroke: 100mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: MF1/MF2 front flange, MB1/MB2 rear flange, MP4 pivot bracket
- Material: Aluminum alloy cylinder tube, hard chrome-plated piston rod
- Seal material: NBR (standard), optional Fluorocarbon for high temp
- Locking force: 3000N max (mechanical spring lock mechanism)
- Temperature range: -20℃ to 80℃ (extended to 150℃ with special seals)
- Weight: 3.8kg (excluding accessories)
- Dimensions: 300mm(L) × 50mm(W) × 50mm(H) (stroke-dependent length)
- Rod thread: M16×1.5
- Protection rating: IP65 (standard), IP67 optional
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-action mechanical locks activated by spring force upon air pressure loss. Precision ground rod prevents lateral play during locking, with hardened guide rings for wear resistance. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in material handling systems
- Emergency stop positioning in automated assembly lines
- Safety clamping in CNC machining fixtures
- Elevator brake backup systems
- Rotary index table stabilization
Installation note:
Lock engages automatically at stroke ends - ensure proper end position alignment.
Lubricate piston rod weekly with ISO VG32 hydraulic oil. Avoid side loads exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SCLB50X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
| Lock Position | Rear Cover with Lock Type |
