Airtac SCLB Rear Lock-Type Cylinder SCLB50X125-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X125-S Locking Cylinder Specifications
- Model: SCLB50X125-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.8 MPa
- Lock holding force: 1,470 N (at 0.5 MPa)
- Cushioning type: Adjustable buffer at both ends
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Mounting style: Standard MF1 flange mounting
- Port size: PT1/4 (G1/8 optional)
- Weight: 3.7 kg ±2%
- Dimensions: 256mm(L) × 62mm(W) × 62mm(H)
- Rod thread: M16×1.5 external thread
- Lock release pressure: ≤0.15 MPa
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-piston lock mechanism for vertical load security. The chromium-plated piston rod and anodized aluminum barrel ensure corrosion resistance in humid environments. Requires 5-40μm filtered air with ISO VG32 lubricant.
- Vertical lifting mechanisms in assembly lines
- Safety clamping during robotic welding
- Position holding in material handling systems
- Emergency stop positioning for CNC tooling
- Overhead load fixation in automotive jigs
Operation note:
Engage lock by depressurizing both ports simultaneously.
Always maintain lubrication (1 drop ISO VG32 oil per 1 million cycles).
Avoid side loads exceeding 30N to prevent lock mechanism wear.
Critical parameters:
- Max lateral load: 150N at full extension
- Lock engagement time: <0.3 sec after pressure release
- Cycle rate: ≤300 cycles/min (with lock)
| Property | Property Value |
|---|---|
| sku | SCLB50X125-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 125mm |
| Lock Position | Rear Cover with Lock Type |
