Airtac SCLB Rear Lock-Type Cylinder SCLB50X150
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X150 Locking-Type Cylinder Specifications
- Model: SCLB50X150
- Type: Double-acting with mechanical lock
- Bore size: Ø50 mm
- Stroke: 150 mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Locking force: 1,200 N (at 0.5 MPa)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange/Foot-mounted (ISO 15552 standard)
- Port size: G1/8 (NPT1/4 optional)
- Seal material: NBR/PU hybrid seals
- Repeat positioning accuracy: ±0.5 mm
- Max piston speed: 500–750 mm/s
- Protection rating: IP67 (dust/water resistant)
- Weight: 2.65 kg (excluding accessories)
- Dimensions: 350mm(L) × 76mm(W) × 90mm(H)
Industrial-grade locking cylinder featuring dual safety mechanisms: pneumatic holding during operation and mechanical locking during power/pressure loss. The chrome-plated piston rod with wear-resistant guide bands ensures smooth operation under lateral loads. Requires ISO VG32 hydraulic oil mist lubrication (0.5–1.0 cc/m³ air).
- Vertical lifting systems requiring position retention
- Emergency stop mechanisms in press machines
- Position holding in robotic welding fixtures
- Safety locking in automated assembly stations
- Overhead material handling systems
Installation note:
Locking mechanism requires 0.3 MPa minimum pressure for disengagement.
Always engage manual release lever during maintenance.
Avoid side load exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | SCLB50X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 150mm |
| Lock Position | Rear Cover with Lock Type |
