Airtac SCLB Rear Lock-Type Cylinder SCLB50X175-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X175-S Locking Cylinder Technical Details
- Model: SCLB50X175-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 50mm
- Stroke: 175mm
- Operating pressure: 0.1-0.9 MPa
- Locking mechanism: Dual-piston wedge system
- Operation direction: Bidirectional locking (extends/retracts)
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Basic (standard) with multiple mounting accessories available
- Port size: G1/4 (NPT1/4 optional)
- Temperature range: -20℃ to 80℃
- Rod material: Chrome-plated steel (S45C)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR + PU hybrid seals
- Protection rating: IP65 (standard), IP67 optional
- Weight: 3.8kg (excluding accessories)
- Dimensions: 275mm(L) × 76mm(W) × 76mm(H) (retracted state)
High-precision locking cylinder featuring fail-safe mechanical position retention. The dual-piston wedge locking mechanism provides 2.5kN holding force (at 0.5MPa) without energy consumption. Corrosion-resistant construction with wear-compensation seals ensures >5,000km service life. Requires 25μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in automated material handling
- Safety positioning in automotive welding fixtures
- Precision stage locking in semiconductor manufacturing
- Emergency brake systems for overhead conveyors
- Mold clamping mechanisms in injection molding
Installation guidelines:
Maintain <2° angular misalignment during mounting. Perform lock engagement test
at 0.3MPa before full operation. Lubricate lock mechanism every 500km of travel
using ISO VG32 hydraulic oil. Avoid side-load forces exceeding 200N.
| Property | Property Value |
|---|---|
| sku | SCLB50X175-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 175mm |
| Lock Position | Rear Cover with Lock Type |
