Airtac SCLB Rear Lock-Type Cylinder SCLB50X200-S
$94.31
Regular price
$101.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLB50X200-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinders are classified into two types: front-cover locking configuration and rear-cover locking configuration.
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
Operational guidance:
Engage locking mechanism only when cylinder is fully stopped.
Lubricate every 3 months under normal use (monthly in high-cycle applications).
Avoid side loads exceeding 50N to prevent premature wear.
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X200-S Locking Cylinder Technical Specifications
- Model: SCLB50X200-S
- Type: Double-acting cylinder with mechanical locking
- Bore size: 50mm
- Stroke: 200mm
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,200N (at 0.5MPa)
- Locking method: Spring-engaged wedge mechanism
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front flange (ISO 15552 standard)
- Seal material: High-grade NBR
- Ambient temperature: -20℃ to +80℃
- Weight: 3.2kg ±5%
- Dimensions: 330mm(L) × 50mm(Bore Ø) × 76mm(H) (including mounting hardware)
- Rod thread: M16×1.5
- Port size: G1/8
- Repeat positioning accuracy: ±0.5mm
Industrial-grade locking cylinder featuring fail-safe position retention even during sudden air pressure loss. The hardened chromium piston rod and dual-lip seals ensure 5,000km+ service life under standard conditions. Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
Typical Applications:
- Vertical load braking in automated assembly lines
- Emergency stop positioning in material handling systems
- Precision fixturing for CNC machine tooling
- Safety interlocks in press machinery
- Position retention in tilt-controlled platforms
Operational guidance:
Engage locking mechanism only when cylinder is fully stopped.
Lubricate every 3 months under normal use (monthly in high-cycle applications).
Avoid side loads exceeding 50N to prevent premature wear.
| Property | Property Value |
|---|---|
| sku | SCLB50X200-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <200mm> |
| Lock Position | Rear Cover with Lock Type |
