Airtac SCLB Rear Lock-Type Cylinder SCLB50X225-S
$95.86
Regular price
$103.36
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLB50X225-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinders are classified into two types: front-cover locking configuration and rear-cover locking configuration.
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
Installation note:
Locking mechanism requires manual release via auxiliary port during maintenance.
Lubricate guide rails with ISO VG32 hydraulic oil monthly in high-cycle applications (>500 cycles/day).
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X225-S Locking Cylinder Specifications
- Model: SCLB50X225-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 225 mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,250 N (at 0.5 MPa)
- Lock release pressure: ≥0.3 MPa
- Mounting style: ISO/VDMA standard (front/rear flange options)
- Piston rod thread: M20×1.5
- Cushioning: Adjustable elastic cushion (both ends)
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃ (dry air required above 0℃)
- Weight: 3.8 kg ±2%
- Dimensions: 325mm(L) × 62mm(W) × 62mm(H) (extended length: 550mm)
- Port size: G1/4 (ISO standard)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty locking cylinder featuring dual safety mechanisms: mechanical position lock and pneumatic pressure retention. The self-lubricating guide bush ensures smooth operation under side load conditions. Requires 5-40μm filtered air with ISO 8573-1:2010 Class 3.2.3 quality.
Typical Applications:
- Vertical lifting mechanisms requiring position hold (e.g., elevator safety brakes)
- Press machine tooling with mid-stroke positioning
- Automated welding fixtures with vibration resistance
- Material handling systems requiring emergency stop position retention
Installation note:
Locking mechanism requires manual release via auxiliary port during maintenance.
Lubricate guide rails with ISO VG32 hydraulic oil monthly in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SCLB50X225-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 225mm |
| Lock Position | Rear Cover with Lock Type |
