Airtac SCLB Rear Lock-Type Cylinder SCLB50X25
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X25 Locking-Type Cylinder Specifications
- Model: SCLB50X25
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 50mm
- Stroke: 25mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,080N (at 0.5MPa)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Mounting options: Basic type, front flange (MF1), rear clevis (MP4)
- Weight: 2.45kg (without accessories)
- Dimensions: 200mm(L) × 58mm(W) × 58mm(H) (extended length)
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–800mm/s
- Protection rating: IP54 (standard), IP67 (optional)
Heavy-duty locking cylinder featuring dual safety mechanisms: pneumatic holding during operation and mechanical locking during power failure. The hardened stainless steel locking pin engages automatically when air pressure drops below 0.15MPa. Includes wear-resistant guide bands for precise linear motion.
- Emergency stop systems in press machinery
- Vertical load holding in material handling equipment
- Position retention in robotic welding arms
- Safety locking in elevator brake systems
- Workpiece clamping in CNC machining centers
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Locking mechanism engages only at stroke ends - ensure proper stroke adjustment.
Maintain 0.3mm minimum clearance around piston rod during system design.
| Property | Property Value |
|---|---|
| sku | SCLB50X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <25 mm> |
| Lock Position | Rear Cover with Lock Type |
