Airtac SCLB Rear Lock-Type Cylinder SCLB50X250
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X250 Locking Cylinder Technical Specifications
- Model: SCLB50X250
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: Ø50 mm
- Stroke: 250 mm
- Operating pressure: 0.1–0.9 MPa
- Locking force: 1,960 N (at 0.5 MPa)
- Locking method: Bidirectional mechanical lock (manual release option)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard MF1/MF2 flange or foot mounting
- Port size: G1/8 (NPT1/4 optional)
- Rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: Nitrile rubber (HNBR optional)
- Ambient temperature: -20℃ to +80℃
- Weight: 3.5 kg ±2%
- Dimensions:
- Total length: 378 mm (including rod)
- Body diameter: Ø58 mm
- Mounting hole spacing: 60 mm (MF1 pattern)
- Rod thread: M16×1.5
- Protection class: IP65 (standard), IP67 (optional)
- ISO standard: 15552
Heavy-duty locking cylinder designed for position retention in vertical/horizontal applications. Features dual-safety locking with position detection slots for magnetic sensors (M9/M12). Anti-rotation rod design ensures precise alignment, with hardened guide bushings for extended service life. Requires 40 μm filtered air and ISO VG32 hydraulic oil lubrication.
- Automated assembly line position locking
- Press machine safety interlock systems
- Material handling vertical load braking
- Automotive welding fixture positioning
- Elevator emergency stop mechanisms
Installation requirements:
Maintain 0.5-1mm clearance between locking mechanism and stopper.
Lubricate sliding surfaces with AirTAC PPS1 grease monthly.
Maximum side load: 150N.
Not suitable for continuous impact applications (>3Hz cycle rate).
| Property | Property Value |
|---|---|
| sku | SCLB50X250 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <250MM> → <250mm> |
| Lock Position | Rear Cover with Lock Type |
