Airtac SCLB Rear Lock-Type Cylinder SCLB50X350-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X350-S Locking Cylinder Specifications
- Model: SCLB50X350-S
- Type: Double-acting cylinder with mechanical lock
- Bore diameter: 50 mm
- Stroke: 350 mm
- Operating pressure: 0.1–0.9 MPa
- Locking force: 1,960 N (at 0.5 MPa)
- Locking method: Manual release lever with spring return
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G1/8 (M5 optional)
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 3.8 kg ±2%
- Dimensions:
- Total length (extended): 644 mm
- Body diameter: 63 mm
- Mounting base: 100×50 mm
- Rod end thread: M16×1.5
Heavy-duty locking cylinder featuring fail-safe mechanical position retention. The dual-piston locking mechanism engages automatically upon pressure loss, preventing unintended movement. Precision ground rod and integrated wear rings ensure 50km maintenance-free operation under standard conditions. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Vertical lifting systems in automotive assembly lines
- Position locking in injection molding ejection units
- Safety brakes for overhead material handling
- Precision fixturing in CNC machining centers
- Emergency stop systems for press machinery
Installation protocol:
Lubricate with ISO VG32 hydraulic oil before initial use.
Locking mechanism requires minimum 0.3 MPa pressure for disengagement.
Avoid side-load exceeding 50N during operation.
Critical note:
Manual override should only be engaged when system is depressurized.
Regular inspection of lock teeth (every 500,000 cycles recommended).
| Property | Property Value |
|---|---|
| sku | SCLB50X350-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 350mm |
| Lock Position | Rear Cover with Lock Type |
