Airtac SCLB Rear Lock-Type Cylinder SCLB50X360-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB Series Locking Cylinder SCLB50X360-S Technical Details
- Model: SCLB50X360-S
- Type: Rear mechanical locking double-acting cylinder
- Bore size: Ø50 mm
- Stroke: 360 mm
- Operating pressure: 0.1–0.9 MPa
- Locking force: 1,200 N (at 0.5 MPa)
- Port size: G1/2 (BSPP thread)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to +80℃
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seals: NBR (standard), optional Fluorocarbon
- Weight: 4.8 kg (excluding accessories)
- Dimensions:
- Extended length: 726 mm
- Retracted length: 366 mm
- Mounting base: 125mm(W) × 50mm(H)
- Protection class: IP54 (standard), IP67 optional
- Position detection: Compatible with magnetic sensors (SM/SD series)
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, designed for vertical load holding and emergency stop applications. Features dual-position locking activated by air pressure release, with tungsten carbide-coated locking pins for wear resistance. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical press machine safety brakes
- Automated welding fixture position retention
- Overhead material handling emergency stops
- Injection molding core puller locking
- Elevator safety mechanisms
Installation requirements:
- Must be mounted with ±0.2mm alignment tolerance
- Requires 0.6 MPa minimum pressure for lock release
- Monthly lubrication recommended (ISO VG32 turbine oil)
- Safety factor ≥2 required for vertical load calculations
| Property | Property Value |
|---|---|
| sku | SCLB50X360-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <360mm> |
| Lock Position | Rear Cover with Lock Type |
