Airtac SCLB Rear Lock-Type Cylinder SCLB50X380-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB Series Locking Cylinder - SCLB50X380-S Technical Details
- Model: SCLB50X380-S
- Type: Double-acting pneumatic cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 380 mm
- Operating pressure: 0.1-1.0 MPa
- Locking mechanism: Pneumatic release/spring lock
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable elastic cushion (both ends)
- Mounting style: Basic MF1 (ISO 15552 standard)
- Port size: G1/2 (BSPP thread)
- Rod material: Chrome-plated steel (Cr-Mo)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 5.8 kg ±2%
- Dimensions (L×W×H): 580mm × 62mm × 62mm (stroke extended)
- Lock holding force: 1,960 N (at 0.5 MPa)
- Repeat positioning accuracy: ±0.2 mm
- Protection class: IP54 (standard wiper seal)
Industrial-grade locking cylinder designed for vertical load holding applications requiring position retention during power/pneumatic failure. Features dual safety mechanism combining spring-applied brake and pneumatic release, with hardened guide rings for anti-rotation stability. Requires 40μm filtered air with recommended 1-3% lubricant oil content (ISO VG32).
- Vertical press machine safety brakes
- Automotive welding fixture position locks
- Material handling elevator emergency stops
- Die-casting machine mold securing
- Automated warehouse vertical axis locking
Installation warning:
Locking mechanism requires 0.3-0.7 MPa control pressure for release.
Always install manual override valve in parallel for emergency position adjustment.
Minimum 50mm maintenance clearance required at rod end.
| Property | Property Value |
|---|---|
| sku | SCLB50X380-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 380mm |
| Lock Position | Rear Cover with Lock Type |
