Airtac SCLB Rear Lock-Type Cylinder SCLB50X40
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X40 Locking Cylinder Technical Details
- Model: SCLB50X40
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: Ø50 mm
- Stroke: 40 mm (±1mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Locking force: 1,200 N (at 0.5 MPa)
- Piston speed: 50-800 mm/s
- Cushioning: Adjustable rubber buffer + shock absorber
- Port size: Rc1/4 (G1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, Chrome-plated steel rod
- Seal type: NBR seals with wear-resistant ring
- Protection class: IP54 (standard), IP67 (optional)
- Weight: 2.8 kg (without accessories)
- Dimensions: 230mm(L) × 60mm(W) × 60mm(H) (fully retracted)
- Mounting options: Basic type (no foot) with multiple accessory brackets available
High-precision locking cylinder featuring dual safety mechanisms - pneumatic holding and mechanical braking. The integrated wedge-block locking system activates automatically during pressure loss, maintaining position within ±0.5mm deviation. Corrosion-resistant design with hard anodized treatment for industrial environments.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in CNC tool changers
- Safety braking for material handling robots
- Precision fixturing in semiconductor manufacturing
- Elevator emergency lock systems
Installation requirements:
Requires clean compressed air (ISO 8573-1:2010 Class 3.4.2) with 20-30μm filtration.
Lubrication: ISO VG32 turbine oil recommended for sliding parts.
Lock engagement time: Allow 0.5-1 second stabilization after pressure cut-off.
| Property | Property Value |
|---|---|
| sku | SCLB50X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <40mm> |
| Lock Position | Rear Cover with Lock Type |
