Airtac SCLB Rear Lock-Type Cylinder SCLB50X450-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X450-S Locking Cylinder Technical Details
- Model: SCLB50X450-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50mm
- Stroke: 450mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,200N (at 0.5MPa)
- Lock release pressure: ≥0.3MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO standard)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated carbon steel
- Weight: 6.8kg (dry, without accessories)
- Dimensions:
- Extended length: 742mm
- Retracted length: 292mm
- Body width: 70mm (mounting block included)
- Height (with rod): 100mm
- Mounting type: Standard ISO 15552 foot-mount with optional accessories
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, designed for vertical load holding and precise position retention. Features dual-stage sealing system with wiper ring for harsh environments. Requires filtered air (≤40μm) with recommended ISO VG32 hydraulic oil mist lubrication (1 drop/cycle).
- Automated material handling systems (vertical lifts)
- Die casting machine safety locking
- Automotive assembly line positioning fixtures
- Press machine intermediate stroke holding
- Warehouse vertical shutter emergency brakes
Installation note:
Requires 100mm front-end clearance for rod extension. Lock mechanism
engages automatically at power loss - manual override requires 5Nm torque.
Lubricate guide shafts monthly with EP2 grease.
| Property | Property Value |
|---|---|
| sku | SCLB50X450-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 450mm |
| Lock Position | Rear Cover with Lock Type |
