Airtac SCLB Rear Lock-Type Cylinder SCLB50X50
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X50 Locking Cylinder Specifications
- Model: SCLB50X50
- Type: Double-acting pneumatic cylinder with mechanical locking
- Bore size: 50mm (ISO standard)
- Stroke: 50mm (adjustable cushioning)
- Operating pressure: 0.15–1.0 MPa
- Locking force: ≥500N (at 0.5MPa)
- Piston speed: 50–800mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting style: Square flange (ISO 15552 compliant)
- Rod end: Female thread M16×1.5
- Seal material: NBR + Polyurethane
- Body material: Anodized aluminum alloy
- Weight: 2.7kg (without accessories)
- Dimensions: 208mm(L) × 76mm(W) × 76mm(H) (retracted length)
- Port size: G1/8 (BSPP thread)
- Position detection: Pre-installed magnet for sensor mounting
High-precision locking cylinder featuring a fail-safe mechanical brake mechanism that activates automatically during power loss. The dual-piston locking design ensures zero drift under load, with IP67 protection for harsh environments. Requires 40μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Vertical lifting systems in automated warehouses
- Position retention in CNC machine tool changers
- Safety locking in automotive assembly fixtures
- Precision holding in semiconductor handling robots
- Emergency stop mechanisms for material handling
Installation notes:1. Lubricate with ISO VG32 hydraulic oil if using non-lubricated air
2. Locking engagement requires ≥0.3MPa air pressure
3. Allow 0.5mm clearance between rod end and load during alignment
4. Annual maintenance recommended for brake pads (50,000km cycle life)
| Property | Property Value |
|---|---|
| sku | SCLB50X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <50mm> |
| Lock Position | Rear Cover with Lock Type |
