Airtac SCLB Rear Lock-Type Cylinder SCLB50X50-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X50-S Locking-Type Cylinder Specifications
- Model: SCLB50X50-S
- Type: Double-acting cylinder with mechanical lock
- Bore diameter: 50 mm
- Stroke: 50 mm
- Operating pressure: 0.1–1.0 MPa
- Locking force: ≥350 N (at 0.5 MPa)
- Lock release pressure: 0.15–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning type: Adjustable rubber bumper
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR/PU
- Weight: 3.2 kg (with standard accessories)
- Dimensions: 200mm(L) × 60mm(W) × 60mm(H) (minimum retracted length)
- Protection rating: IP54 (standard) / IP67 (optional with wiper upgrade)
High-precision locking cylinder featuring dual safety mechanisms: spring-assisted mechanical lock and pneumatic lock release. The hardened chrome piston rod and multi-lip seals ensure ≤0.05mm position retention accuracy after 100km stroke cycles. Requires filtered air (≤40μm) with ISO VG32 hydraulic oil mist lubrication (0.5-1.0 cSt).
- Vertical load holding in automated assembly lines
- Emergency stop position retention in material handling systems
- Precision fixturing for CNC machining centers
- Safety interlocks in press brake tooling
- Elevator door locking mechanisms
Installation protocol:
Mount with ±0.2mm alignment tolerance. Engage lock manually before initial operation.
Lubricate every 50km of travel. Lock release pressure must exceed system pressure by 0.05MPa minimum.
| Property | Property Value |
|---|---|
| sku | SCLB50X50-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <50mm> |
| Lock Position | Rear Cover with Lock Type |
