Airtac SCLB Rear Lock-Type Cylinder SCLB50X55-S
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X55-S Locking Cylinder Technical Specifications
- Model: SCLB50X55-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50 mm (±0.1mm tolerance)
- Stroke: 55 mm (adjustable ±2mm)
- Operating pressure: 0.1-0.8 MPa
- Locking force: 1,200N (at 0.5MPa)
- Lock activation: Manual release lever + auto-lock on pressure drop
- Cushioning: Adjustable rubber buffers (both ends)
- Material: Aluminum alloy body (A6063-T5), CRMo steel piston rod
- Seal type: NBR seals with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Port size: 1/4 NPT (G1/4 optional)
- Weight: 1.65 kg (without accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (extended length)
- Rod thread: M16×1.5 external thread
- Protection class: IP54 (standard), IP67 (optional)
Industrial-grade locking cylinder featuring dual safety mechanism: automatic position locking during power/pressure loss and manual override capability. The hardened piston rod (HRC 35-40) withstands side loads up to 150N. Requires ISO VG32 hydraulic oil lubrication for optimal seal performance.
- Safety brakes in automated assembly lines
- Position retention in material handling elevators
- Emergency stop mechanisms for CNC tool changers
- Load locking in automated warehouse stackers
- Precision fixturing in semiconductor manufacturing
Installation protocol:
Mount with 0.05mm maximum misalignment tolerance. Always engage lock
during maintenance using the manual override lever. Lubricate monthly
with AirTAC PX-22 grease. Avoid rapid pressure drops >0.3MPa/sec.
Critical note:
Locking mechanism requires minimum 0.3MPa residual pressure for
smooth disengagement. Never use impact tools on adjustment screws.
| Property | Property Value |
|---|---|
| sku | SCLB50X55-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 55mm |
| Lock Position | Rear Cover with Lock Type |
