Airtac SCLB Rear Lock-Type Cylinder SCLB50X75
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X75 Locking Cylinder Technical Specifications
- Model: SCLB50X75
- Type: Double-acting with mechanical lock (rod lock)
- Bore size: Ø50 mm
- Stroke: 75 mm
- Operating pressure: 0.1-1.0 MPa
- Temperature range: -20℃ to 80℃
- Locking mechanism: Spring-activated wedge system
- Cushioning type: Adjustable pneumatic cushion
- Mounting style: Standard MF1 (front flange)
- Port size: G1/2 (ISO228/1)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy barrel, hardened chrome-plated rod
- Seal material: NBR + PU combination
- Repeat positioning accuracy: ±0.5 mm
- Max locking force: 2,500 N (at 0.5 MPa)
- Max lateral load: 300 N
- Weight: 2.85 kg (excluding accessories)
- Dimensions: 300mm(L) × 90mm(W) × 90mm(H) (retracted state)
- Protection rating: IP67 (rod extended), IP54 (with lock engaged)
Heavy-duty locking cylinder featuring fail-safe mechanical position retention, designed for vertical load applications requiring mid-stroke position holding. The dual-piston design ensures stable locking force distribution, with corrosion-resistant construction for harsh environments. Requires 5-40μm filtered lubricated air (ISO8573-1 class 4).
- Automated assembly line clamping fixtures
- Vertical press brake tool positioning
- Material handling emergency stop systems
- Die casting machine safety interlocks
- Elevator brake test equipment
Installation note:
Requires minimum 0.3 MPa air pressure for lock release.
Lubricate rod weekly with ISO VG32 hydraulic oil.
Avoid side load exceeding 5% of maximum capacity during operation.
| Property | Property Value |
|---|---|
| sku | SCLB50X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 75mm |
| Lock Position | Rear Cover with Lock Type |
