Airtac SCLB Rear Lock-Type Cylinder SCLB50X900
2. Unlocking modes: automatic and manual.
Category: Locking Cylinders | Brand: Airtac | Series: SCLB
AirTAC SCLB50X900 Locking Cylinder Technical Details
- Series: SCLB Locking Cylinder Series
- Bore size: 50mm (ISO 6432 standard)
- Stroke: 900mm (adjustable stroke version available)
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥2,450N @ 0.5MPa
- Locking method: Mechanical wedge-type dual locking
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Mounting type: Basic type (MF1) with front flange
- Rod end: External thread M20×1.5
- Seal material: NBR + PU combination
- Ambient temperature: -10℃ to 80℃
- Weight: 6.8kg (without accessories)
- Dimensions: 1,185mm(L) × 72mm(W) × 72mm(H)
- Port size: G1/8 (ISO standard porting)
- Rod surface treatment: Hard chrome plating (20-25μm)
- Repeat positioning accuracy: ±0.5mm
- ISO certification: ISO 6432:2015 compliant
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, designed for vertical load holding and emergency stop scenarios. Features dual piston seals with wear compensation and anti-rotation guide bushings. Requires 5-40μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional oil-free operation).
- Vertical press machine safety brakes
- Automated warehouse lifting systems
- Robotic welding positioners
- Die-casting machine mold locking
- Solar panel tilt adjustment mechanisms
- Elevator emergency stop systems
Installation requirements:
Maintain 0.5mm minimum alignment tolerance during mounting.
Requires weekly lubrication (Molykote 111 recommended) for optimal brake performance.
Not suitable for horizontal impact loading without additional guide mechanisms.
| Property | Property Value |
|---|---|
| sku | SCLB50X900 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <900mm> |
| Lock Position | Rear Cover with Lock Type |
