Airtac SCLF Front Locking Cylinder SCLF40X125-S
$75.18
Regular price
$82.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLF40X125-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking mechanism configurations: Front cover locking type and Rear cover locking type;
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
Critical installation requirement:
Must maintain alignment tolerance ≤0.2mm/m between cylinder axis and guided load.
Use alignment couplers for non-rigid connections.
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF Series Front Lock Cylinder SCLF40X125-S Technical Specifications
- Model: SCLF40X125-S
- Bore size: 40mm
- Stroke: 125mm
- Operating pressure: 0.1-1.0 MPa
- Locking force: 1,960N (at 0.5MPa)
- Locking method: Mechanical wedge mechanism
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Standard MF1/MF2 flange
- Port size: M5x0.8 (G1/8 adapter optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Protection class: IP54 (standard), IP67 (optional)
- Weight: 2.8kg ±3%
- Dimensions:
- Length: 229mm (fully extended)
- Width: 72mm (mounting flange)
- Height: 72mm (including lock unit)
High-precision locking cylinder with integrated mechanical brake system, featuring zero-backlash position holding capability. The double piston rod design ensures stable operation under lateral forces. Requires 5μm filtered air supply and regular lubrication (ISO VG32 recommended).
Typical Applications:
- Precision fixturing in CNC machining centers
- Vertical axis locking in automated material handling
- Safety positioning in semiconductor wafer handling
- Overhead load securing in automotive assembly lines
- Position retention in robotic welding jigs
Operation Notes:
- Lock engagement requires minimum 0.3MPa air pressure
- Allow 0.5-1 second delay between motion stop and lock activation
- Maximum permissible side load: 300N at rod end
- Lubrication interval: Every 500km of cumulative travel
Critical installation requirement:
Must maintain alignment tolerance ≤0.2mm/m between cylinder axis and guided load.
Use alignment couplers for non-rigid connections.
| Property | Property Value |
|---|---|
| sku | SCLF40X125-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
