Airtac SCLF Front Locking Cylinder SCLF40X15
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF40X15 Front Lock Cylinder Technical Details
- Model: SCLF40X15
- Bore size: 40mm
- Stroke: 15mm
- Operation type: Double-acting with mechanical lock
- Locking method: Manual release lever (front position lock)
- Working pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/4 (ISO standard)
- Piston speed: 50–800 mm/s
- Seal material: NBR (nitrile rubber)
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Weight: 1.85 kg (without accessories)
- Dimensions: 200mm(L) × 48mm(W) × 48mm(H)
- Mounting type: Standard ISO 15552 foot mounting
- Protection class: IP54 (standard sealing)
High-precision locking cylinder with fail-safe mechanical position retention. Features dual anti-rotation guide rods for enhanced stability during locking operations. The corrosion-resistant construction includes hard chrome piston rod and wear-resistant seals, suitable for high-cycle applications. Requires air filtration of 5-40μm.
- Position holding in automated assembly line jigs
- Safety locking in press machine tooling
- Vertical load braking in material handling systems
- Precision stop mechanisms in semiconductor manufacturing
- Emergency position freeze in robotic welding arms
Installation notes:
- Always engage lock mechanism before system pressurization
- Maintain 0.5mm minimum clearance between lock lever and adjacent components
- Lubricate with ISO VG32 hydraulic oil if used in vertical orientation
- Verify lock engagement every 50,000 cycles for maintenance
| Property | Property Value |
|---|---|
| sku | SCLF40X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <15mm> |
| Lock Position | Front Cover with Lock |
