Airtac SCLF Front Locking Cylinder SCLF40X200
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF40X200 Front Lock Cylinder Specifications
- Model: SCLF40X200
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥500N (at 0.5MPa)
- Port size: M5x0.8 (G1/8 equivalent)
- Cushioning: Adjustable elastic cushion
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy barrel, CRMo steel piston rod
- Mounting: Standard ISO 15552 (preferred) or optional foot mounting
- Weight: 2.8kg ±5%
- Dimensions: 272mm(L) × 50mm(W) × 50mm(H) (retracted state)
- Rod end thread: M16×1.5
- Lock release pressure: 0.15MPa minimum
- Repeat positioning accuracy: ±0.5mm
Heavy-duty locking cylinder with fail-safe mechanical brake mechanism, featuring dual piston seals and chrome-plated rod for enhanced durability. The integrated lock engages automatically when air pressure drops, preventing unintended movement. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Vertical load holding in material handling systems
- Emergency stop positioning in assembly robots
- Safety locking in die-casting machine platens
- Position retention in automated warehouse elevators
- Overhead load stabilization in crane mechanisms
Installation note:
Maintain 0.5mm minimum clearance between lock mechanism and mounting surface.
Perform lock adjustment via hex socket (3mm Allen key) after installation.
Lubricate weekly with AirTAC PPS2 grease in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SCLF40X200 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <200mm> |
| Lock Position | Front Cover with Lock |
