Airtac SCLF Front Locking Cylinder SCLF40X25
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF40X25 Front Lock Cylinder Technical Details
- Model: SCLF40X25
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø40 mm
- Stroke: 25 mm (standard option, customizable)
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,200 N max (at 0.5 MPa)
- Lock mechanism: Wedge-type mechanical lock (front position)
- Port size: Rc1/4 (G1/4 optional)
- Cushioning: Adjustable air cushion (both ends)
- Seal material: Nitrile Butadiene Rubber (NBR)
- Temperature range: -20℃ to 80℃
- Protection rating: IP67 (dust/immersion resistant)
- Weight: 2.3 kg ±5%
- Dimensions: 226mm(L) × 56mm(W) × 56mm(H)
- Rod thread: M16×1.5 (external)
- Mounting options: Front flange, rear foot, or side lug
Heavy-duty locking cylinder with instantaneous position holding capability, featuring a fail-safe mechanical lock that engages automatically at stroke end. The hardened stainless steel rod and dual dust seals ensure durability in harsh environments. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 3).
- Vertical load locking in automated assembly lines
- Safety positioning in CNC tool changers
- Workpiece clamping in precision machining centers
- Emergency stop systems for material handling robots
- Overhead conveyor system braking mechanisms
Installation guidelines:
Engage lock mechanism before system pressurization. Maintain 0.3-0.5 MPa
minimum pressure for reliable unlocking. Lubricate with ISO VG32 hydraulic oil
monthly. Avoid side load exceeding 10% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SCLF40X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <25 mm> |
| Lock Position | Front Cover with Lock |
