Airtac SCLF Front Locking Cylinder SCLF50X150
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF50X150 Front Lock Cylinder Technical Details
- Model: SCLF50X150
- Bore size: Ø50 mm
- Stroke: 150 mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,960 N (at 0.5 MPa)
- Lock type: Mechanical wedge lock (manual release optional)
- Cushioning: Adjustable pneumatic cushion
- Port size: Rc1/4 (NPT1/4 optional)
- Operating temperature: -10℃ to 70℃
- Piston speed: 50–800 mm/s
- Weight: 3.8 kg (without accessories)
- Dimensions: 226mm(L) × 50mm(Bore) × 72mm(H) (locked state)
- Rod thread: M16×1.5
- Seal material: NBR + PU combination
- Protection class: IP54 (standard), IP67 (optional)
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-action wedge locking mechanism that engages automatically at stroke ends. The hardened stainless steel rod and multi-lip seals ensure reliable operation in high side-load applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in material handling systems
- Safety clamping in automotive welding fixtures
- Position locking in CNC machine tool changers
- Emergency stop mechanisms in press machines
- Elevator brake systems (non-personnel transport)
Installation note:
Locking mechanism requires periodic lubrication (ISO VG32).
Maintain minimum 0.3 MPa pressure during unlocking operation.
Avoid side loads exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SCLF50X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
