Airtac SCLF Front Locking Cylinder SCLF50X175
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF50X175 Front Lock Cylinder Technical Details
- Model: SCLF50X175
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 175 mm
- Operating pressure: 0.1–1.0 MPa
- Locking force: 1,200 N (max)
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO228/1 standard)
- Mounting type: Standard ISO 15552 foot and flange mounts
- Rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seals: NBR/PU compound seals
- Weight: 2.65 kg (unpiped)
- Dimensions:
- Total length: 275 mm (stroke + end caps)
- Body diameter: Ø50 mm
- Mounting hole spacing: 60 mm (center-to-center)
- Rod thread: M16×1.5
- Protection rating: IP65 (rod extended)
Heavy-duty locking cylinder featuring dual-position mechanical brake system with manual override. The integrated wedge-lock mechanism maintains position during power loss, with 360° adjustable locking force via hex key. Corrosion-resistant construction with wear indicator window for maintenance monitoring. Requires filtered air (≤5μm) with ISO VG32 hydraulic oil mist lubrication (0.1-0.3 mL/m³).
- Press machine safety interlock systems
- Automated welding fixture position retention
- Vertical load holding in material handling
- Mold clamping in injection molding machines
- Emergency stop mechanisms for CNC equipment
Installation protocol:
Locking mechanism requires 20-30 break-in cycles at 0.3 MPa before full load operation.
Maintain minimum 0.5 MPa residual pressure when disengaging lock. Avoid side loads exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SCLF50X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 175mm |
| Lock Position | Front Cover with Lock |
