Airtac SCLF Front Locking Cylinder SCLF50X200-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF50X200-S Front Lock Cylinder Technical Details
- Model: SCLF50X200-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 50mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,960N (at 0.5MPa)
- Lock mechanism: Spring-activated wedge system
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Standard ISO/VDMA front flange
- Port size: G1/4 (NPT1/4 optional)
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Rod material: Hard chrome-plated steel
- Seal material: NBR/PU
- Weight: 3.2kg (without accessories)
- Dimensions: 320mm(L) × 70mm(W) × 70mm(H)
- Protection rating: IP54 (standard), IP67 (optional wiper upgrade)
Heavy-duty locking cylinder with fail-safe position retention capability. Features dual-safety design combining pneumatic holding force and mechanical interlock. The corrosion-resistant construction includes a scratch-resistant rod coating and integrated mounting grooves for sensor installation. Requires 5-40μm filtered air with ISO VG32 lubricator oil mist.
- Vertical load holding in material handling systems
- Emergency stop positioning in press machinery
- Workpiece clamping in CNC machining centers
- Safety interlocks in automotive assembly lines
- Position retention during power failure scenarios
Installation note:
Lock mechanism requires manual release via the emergency unlock lever before initial operation.
Maintain horizontal mounting (±3° tolerance) for optimal locking force distribution.
Lubricate guide shafts every 2,000km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SCLF50X200-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <200mm> |
| Lock Position | Front Cover with Lock |
