Airtac SCLF Front Locking Cylinder SCLF50X50
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF50X50 Front Locking Cylinder Technical Details
- Model: SCLF50X50
- Type: Double-acting pneumatic cylinder with mechanical lock
- Bore size: Ø50 mm
- Stroke: 50 mm (Customizable: 25-500 mm)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Locking force: 1,960 N (at 0.5 MPa)
- Mounting type: Standard ISO/VDS 24552 base mounting
- Rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: 2.45 kg (without accessories)
- Dimensions (L×W×H):
- Body length: 132 mm (excluding rod)
- Total extended length: 182 mm (stroke included)
- Mounting base: 80mm × 50mm
- Rod end thread: M16×1.5
- ISO standard: 15552 compliant
- Protection rating: IP54 (standard wiper)
Heavy-duty locking cylinder featuring dual-position mechanical brake mechanism for fail-safe load holding. The integrated wedge-lock system activates automatically at stroke ends, providing zero-backlash stabilization. Optimized for vertical applications requiring position retention during power loss or pressure drop.
- Automated welding fixture position locks
- Vertical elevator safety brakes in cleanrooms
- Press machine intermediate stroke hold
- Solar panel tilt adjustment mechanisms
- Robotic arm overload protection
Installation protocol:
Requires periodic lubrication (ISO VG32 oil mist) every 500km of cumulative stroke.
Lock engagement needs 0.3MPa minimum pressure differential. Avoid side-load exceeding 150N.
| Property | Property Value |
|---|---|
| sku | SCLF50X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
