Airtac SCLF Front Locking Cylinder SCLF50X75
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF Series Front Lock Cylinder SCLF50X75 Specifications
- Model: SCLF50X75
- Bore size: 50mm
- Stroke: 75mm
- Operating pressure: 0.1-0.9 MPa
- Lock holding force: 1,800N (at 0.5MPa)
- Ambient temperature: -20℃ to 80℃
- Cushioning type: Air cushion + external shock absorber
- Mounting style: Front flange with lock mechanism
- Port size: G1/8 (NPT1/8 optional)
- Lock type: Mechanical wedge-lock system
- Material: Aluminum alloy barrel, SUS304 piston rod
- Weight: 2.7kg (dry, without accessories)
- Dimensions: 200mm(L) × 58mm(W) × 58mm(H)
- Protection rating: IP54 (standard), IP67 (optional)
- Piston speed: 50-750mm/s
- Repeat positioning accuracy: ±0.5mm
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-action locking mechanism that engages automatically during power/pneumatic failure. Precision-ground chrome piston rod with wear-resistant seals ensures over 3,000km service life. Requires 5μm filtered air and regular lubrication (ISO VG32 equivalent).
- Vertical load holding in automated assembly lines
- Safety positioning in robotic welding fixtures
- Emergency stop mechanisms for material handling
- Precision clamping in CNC tool changers
- Overhead load locking in automotive jigs
Installation note:
Locking mechanism requires 0.3MPa minimum working pressure for reliable engagement.
Avoid side-load forces exceeding 15% of maximum thrust. Perform monthly lock groove cleaning.
| Property | Property Value |
|---|---|
| sku | SCLF50X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 75mm |
| Lock Position | Front Cover with Lock |
