Airtac SCLF Front Locking Cylinder SCLF63X100
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X100 Front Lock Cylinder Technical Details
- Model: SCLF63X100 (Standard Compact Locking Cylinder)
- Bore size: Ø63mm (±0.02mm manufacturing tolerance)
- Stroke: 100mm (Customizable 25-500mm on request)
- Operation type: Double-acting with mechanical lock
- Working pressure: 0.1-0.9 MPa (14.5-130 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Locking mechanism: Spring-engaged piston rod lock
- Mounting style: Front flange/Foot mount (ISO 15552 compatible)
- Port size: G1/4 (BSPP) or optional NPT1/4
- Seal material: Nitrile butadiene rubber (NBR) standard
- Temperature range: -20℃ to +80℃ (Fluorocarbon seals optional for high temp)
- Weight: 2.8kg ±5% (Without accessories)
- Dimensions: 250mm(L) × 100mm(W) × 100mm(H) (Extended length)
- Rod thread: M16×1.5 external thread (Stainless steel option available)
- Protection rating: IP67 (Dust/water resistant)
- Lubrication: Pre-lubricated (Use ISO VG32 pneumatic oil)
High-precision locking cylinder with fail-safe position retention capability. Features chrome-plated piston rod with wear-resistant guide bushings and integrated magnetic sensor slots (SM/SMF series compatible). The front locking mechanism provides positive position hold without pressure consumption, ideal for emergency stops or energy-saving applications.
- Automated assembly line clamping fixtures
- Material handling vertical load locking
- Press machine safety positioning
- Automotive welding jig stabilization
- Elevator brake safety systems
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Engage lock mechanism only when cylinder is fully extended/retracted.
Perform monthly lubrication checks under high-cycle (＞500,000 strokes/year) operation.
Critical note:
Do NOT disassemble locking unit without factory-trained technicians.
Minimum 0.3MPa pressure required for smooth lock disengagement.
| Property | Property Value |
|---|---|
| sku | SCLF63X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
