Airtac SCLF Front Locking Cylinder SCLF63X1000-S
$181.16
Regular price
$188.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLF63X1000-S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking mechanism configurations: Front cover locking type and Rear cover locking type;
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
Installation guidelines:
Maintain ≤0.5mm/m alignment tolerance during mounting. Apply MIL-PRF-81309F grease
to locking mechanism annually. Lock engagement requires minimum 0.3MPa pressure.
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X1000-S Front Lock Cylinder Technical Details
- Model: SCLF63X1000-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø63mm (±0.1mm tolerance)
- Stroke: 1000mm (40mm increments available)
- Operating pressure: 0.1–0.9 MPa
- Locking force: 1,800N (at 0.5MPa)
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard MF1 flange
- Port size: G1/8 (BSPP thread)
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy body (A6063-T5), CRMo steel piston rod
- Seal material: NBR with wear-resistant ring
- Weight: 9.8kg (±3%)
- Dimensions: 1,178mm(L) × 92mm(W) × 92mm(H)
- Rod thread: M20×1.5 (external)
- Position detection: Optional magnetic switch groove (4-2.5mm)
Heavy-duty locking cylinder featuring dual safety mechanism with spring-assisted mechanical lock and pneumatic interlock. The chrome-plated piston rod (hardness HRC45-50) ensures corrosion resistance in humid environments. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
Industrial Applications:
- Vertical lifting systems requiring position hold (e.g., elevator safety brakes)
- Automated welding fixture positioning
- Press machine intermediate stop mechanisms
- Overhead material handling systems
- Solar panel tilt adjustment systems
Installation guidelines:
Maintain ≤0.5mm/m alignment tolerance during mounting. Apply MIL-PRF-81309F grease
to locking mechanism annually. Lock engagement requires minimum 0.3MPa pressure.
| Property | Property Value |
|---|---|
| sku | SCLF63X1000-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
| Lock Position | Front Cover with Lock |
