Airtac SCLF Front Locking Cylinder SCLF63X125
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X125 Front Locking Cylinder Technical Specifications
- Model: SCLF63X125
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 63 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.8 MPa
- Locking method: Spring-activated mechanical brake (front position lock)
- Port size: M14x1.5 (standard) / NPT1/2 (optional)
- Cushioning type: Adjustable buffer at both ends
- Temperature range: -20℃ to 80℃
- Mounting style: Standard ISO/VDMA mounting pattern
- Material:
- Cylinder tube: Aluminum alloy with hard anodized surface
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: Polyurethane (PU) with wear-resistant design
- Weight: 3.8 kg (without accessories)
- Dimensions: 225mm (L) × 110mm (W) × 110mm (H)
- Locking force: 1,200 N (at 0.5 MPa)
- Response time: ≤0.5 sec (locking engagement)
- Protection rating: IP54 (standard) / IP67 (optional)
The SCLF63X125 features an integrated position-locking mechanism that activates within 0.5 seconds of air pressure loss, making it ideal for vertical load applications requiring fail-safe position retention. Its dual piston design ensures smooth operation even under side load conditions, with tungsten-carbide coated guide rings for enhanced wear resistance.
- Automated material handling systems requiring mid-stroke pause
- Press brake tooling positioning in metal fabrication
- Overhead load suspension in assembly lines
- Injection molding machine core-pull mechanisms
- Semiconductor wafer handling robots
Installation note:
Requires minimum 0.3 MPa working pressure for reliable lock disengagement.
Lubricate sliding surfaces with ISO VG32 hydraulic oil every 6 months.
Avoid angular misalignment exceeding ±2° during mounting.
- Maximum side load capacity: 350 N
- Lock release response: 0.15 MPa minimum pressure required
- Cycle life: 2,000 km travel distance (under standard conditions)
- Re-lubrication interval: 500,000 cycles or 6 months
| Property | Property Value |
|---|---|
| sku | SCLF63X125 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
