Airtac SCLF Front Locking Cylinder SCLF63X150
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X150 Front Lock Cylinder Technical Specifications
- Model: SCLF63X150
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 63mm (±0.1mm tolerance)
- Stroke: 150mm (standard), customizable up to 500mm
- Operating pressure: 0.05-1.0 MPa
- Locking mechanism: Spring-loaded wedge system (manual release option)
- Port size: G1/2 (BSPP thread)
- Cushioning: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃ (NBR seals)/-10℃ to 60℃ (Parker seals)
- Material: Aluminum alloy barrel, hardened steel piston rod (Cr-Mo steel)
- Rod diameter: 20mm (chrome-plated surface)
- Protection rating: IP65 (standard), IP67 optional
- Weight: 1.85kg (bare cylinder), 2.3kg with accessories
- Dimensions: 218mm(L) × 80mm(W) × 80mm(H) (retracted position)
- Max lateral load: 150N at midpoint
- Lock holding force: 3,200N (at 0.5MPa)
Industrial-grade locking cylinder featuring fail-safe position retention, designed for vertical load applications requiring mid-stroke stoppage. The dual-piston locking mechanism prevents accidental movement during power loss, with precision-ground guide rods ensuring ±0.2mm repeat positioning accuracy. Compatible with magnetic sensors (sensor slot included).
- Automated welding fixture position locking
- Press brake tooling height fixation
- Elevator safety brake systems
- Injection molding machine core positioning
- Material handling emergency stop mechanisms
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. Lubricate lock grooves with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, install manual release lever facing downward. Allow 50mm clearance for lock mechanism engagement.
Critical note:
Lock engagement requires minimum 0.3MPa pressure. Avoid side load exceeding 10% of maximum thrust during locking phase.
Perform functional test every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | SCLF63X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
