Airtac SCLF Front Locking Cylinder SCLF63X150-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X150-S Front Lock Cylinder Specifications
- Model: SCLF63X150-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63 mm
- Stroke: 150 mm (±0.5mm tolerance)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Locking force: 1,200 N (at 0.5 MPa)
- Cushioning: Adjustable air cushion (both ends)
- Port size: 1/4" NPT (G1/4 optional)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 3.5 kg (7.7 lbs)
- Dimensions: 250mm(L) × 100mm(W) × 125mm(H)
- Rod thread: M16×1.5
- Mounting: ISO 15552 standard (multiple mounting options available)
- Protection rating: IP65 (dust-tight & protected against water jets)
Heavy-duty locking cylinder designed for vertical load applications requiring position retention during power/pneumatic failure. Features dual safety mechanism with spring-assisted mechanical lock engagement and precision ground rod surface treatment (0.4μm Ra). Requires 40μm filtered air with oil mist lubrication (ISO VG32 recommended).
- Vertical press machine safety brakes
- Automated material handling lift-and-hold systems
- Die casting machine mold locking
- Overhead conveyor emergency stops
- Robotic welding positioners
Installation note:
Lock mechanism requires manual release via side lever before initial operation.
Maintain minimum 0.3 MPa pressure for smooth lock disengagement.
Lubricate lock pins every 50,000 cycles using ISO VG68 grease.
| Property | Property Value |
|---|---|
| sku | SCLF63X150-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
