Airtac SCLF Front Locking Cylinder SCLF63X250
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X250 Front Locking Cylinder Technical Details
- Model: SCLF63X250
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63mm
- Stroke: 250mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Material: Aluminum alloy barrel, hardened steel piston rod
- Rod diameter: 20mm (chrome-plated)
- Locking force: 1,200N max (at 0.5MPa)
- Seal type: NBR rubber seals
- Temperature range: -20℃ to +80℃
- Port size: G1/4 (ISO standard)
- Weight: 3.8kg (excluding accessories)
- Dimensions: 400mm(L) × 63mm(W) × 63mm(H) (extended length)
- Lock release method: Manual lever operation (90° rotation)
- Mounting options: Basic type (no flange), MF1/MF2 front flange, MB1/MB2 rear flange
High-precision locking cylinder with fail-safe position retention capability, featuring dual-position memory function. The integrated mechanical lock mechanism prevents unintended movement during power loss, with precision ground rod guidance (H7 tolerance) for repeat positioning accuracy ±0.2mm. Corrosion-resistant design includes rod wiper and stainless steel end caps.
- Vertical load holding in automated assembly lines
- Safety clamping in press brake tooling systems
- Position locking in material handling robots
- Emergency stop mechanisms for lifting platforms
- Precision fixturing in CNC machining centers
Operational guidance:
Apply ISO VG32 hydraulic oil or equivalent for lubrication.
Maintain 0.3-1mm clearance between lock lever and stopper during installation.
Requires weekly inspection of lock mechanism for debris.
Not recommended for side-load applications exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SCLF63X250 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <250MM> → <250mm> |
| Lock Position | Front Cover with Lock |
