Airtac SCLF Front Locking Cylinder SCLF63X300-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X300-S Locking Cylinder Technical Details
- Model: SCLF63X300-S
- Type: Double-acting cylinder with mechanical locking
- Bore size: Ø63 mm
- Stroke: 300 mm (customizable 250-500mm)
- Operating pressure: 0.15-0.8 MPa
- Cushioning: Adjustable air cushion at both ends
- Locking force: 1,250 N (at 0.5 MPa)
- Lock activation: Manual release button + automatic engagement
- Mounting style: ISO/VDMA Standard flange Mounting
- Port size: G1/4 (NPT1/4 optional)
- Ambient temperature: -20℃ to +80℃
- Seal material: HNBR (hydrogenated nitrile) for high wear resistance
- Rod material: Hard chrome-plated steel
- Weight: 3.8 kg (without accessories)
- Dimensions: 612mm(L) × 80mm(W) × 80mm(H) (extended length)
- Protection class: IP54 (standard), IP67 with optional wiper
Industrial-grade locking cylinder featuring dual safety mechanism - automatic position lock upon pressure loss and manual override capability. Precision ground tube with wear-resistant coating ensures ≤0.01mm internal leakage. Requires 20-40μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in material handling systems
- Emergency stop positioning in automated assembly lines
- Safety clamping in CNC machining fixtures
- Elevator brake systems in cleanroom environments
- Overhead crane position retention mechanisms
Installation protocol:
Must be mounted with ±0.2mm alignment tolerance. Engage lock mechanism
manually after installation to verify smooth operation. Lubricate every
5,000 cycles using ISO VG32 hydraulic oil. Avoid side load exceeding 10%
of maximum thrust capacity.
Critical note:
Lock disengagement requires minimum 0.3MPa air pressure. Never attempt
forced manual release under load without pressure supply. Always install
mechanical end stops for overload protection.
| Property | Property Value |
|---|---|
| sku | SCLF63X300-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | Stroke 300 |
| Lock Position | Front Cover with Lock |
