Airtac SCLF Front Locking Cylinder SCLF63X350-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X350-S Front Lock Cylinder Specifications
- Model: SCLF63X350-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63 mm
- Stroke: 350 mm
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Manual release lever (front-side)
- Port size: Rc1/4 (G1/4 optional)
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Seal material: NBR + PU combination
- Mounting type: Standard ISO 15552 (preferred) / optional foot mounting
- Weight: 5.2 kg (without accessories)
- Dimensions: 580mm(L) × 110mm(W) × 110mm(H) (at full extension)
- Rod thread: M20×1.5 external
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
Heavy-duty lock cylinder featuring fail-safe position retention through mechanical interlock. The anodized aluminum construction with chrome-plated piston rod ensures corrosion resistance in harsh environments. Requires 5-40μm filtered air and ISO VG32 hydraulic oil lubrication (optional auto-lube kits available).
- Automated assembly line clamping fixtures
- Press machine safety position locking
- Overhead load suspension systems
- Die-casting mold stabilization
- Palletizing robot emergency stop positions
Installation note:
Lock engagement requires cylinder to be within ±2mm of stroke end.
Always depressurize before manual lock release. Recommend monthly
lubrication of lock mechanism with MIL-PRF-6083 grease.
Critical parameters:
- Max side load: 250N at full extension
- Lock holding force: 3,800N (static)/2,200N (dynamic)
- Repeat positioning accuracy: ±0.5mm
| Property | Property Value |
|---|---|
| sku | SCLF63X350-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 350mm |
| Lock Position | Front Cover with Lock |
