Airtac SCLF Front Locking Cylinder SCLF63X50
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X50 Front Locking Cylinder Specifications
- Model: SCLF63X50
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 63mm
- Stroke: 50mm (standard), customizable up to 500mm
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable elastic cushion at both ends
- Mounting style: Standard MF2 (front flange) with integrated lock bracket
- Port size: G1/4 (NPT1/4 optional)
- Operating temperature: -10℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Lock mechanism: Spring-assisted mechanical brake
- Repeat positioning accuracy: ±0.5mm
- Max piston speed: 500mm/s
- Protection rating: IP54 (standard), IP67 (optional with wiper upgrade)
- Weight: 2.8kg (excluding accessories)
- Dimensions: 235mm(L) × 85mm(W) × 85mm(H) (at mid-stroke position)
Heavy-duty locking cylinder featuring instantaneous position retention capability through its integrated mechanical brake system. The dual-piston-rod design ensures balanced load distribution, while the hard chrome plating provides exceptional wear resistance. Requires 5μm filtered air and ISO VG32 hydraulic oil lubrication for optimal brake performance.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in stamping presses
- Intermediate position locking in material handling robots
- Safety braking for overhead conveyor systems
- Precision fixturing in CNC machine tool changers
Operational note:
Always depressurize the cylinder before releasing the mechanical lock.
Maintain lubrication intervals every 500km of cumulative travel.
Avoid side loads exceeding 30N to prevent brake wear.
Critical parameters:
Minimum 0.3MPa pressure required for lock disengagement.
Maximum holding force of 1,850N at 0.63MPa.
Allow 15-second cooldown after continuous 50-cycle operations.
| Property | Property Value |
|---|---|
| sku | SCLF63X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
