Airtac SCLF Front Locking Cylinder SCLF63X550
$136.55
Regular price
$144.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLF63X550
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking mechanism configurations: Front cover locking type and Rear cover locking type;
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
Installation note:
Requires minimum 0.3MPa unlocking pressure. Lubricate lock mechanism with ISO VG32 hydraulic oil monthly.
Avoid lateral forces exceeding 30N on piston rod during operation.
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X550 Front Lock Cylinder Technical Details
- Model: SCLF63X550
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø63mm
- Stroke: 550mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,960N (at 0.5MPa)
- Operation method: Air pressure release type locking
- Port size: Rc1/4 (G1/4 optional)
- Locking mechanism: Wedge-type dual piston rod lock
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃
- Weight: 5.8kg (excluding accessories)
- Dimensions: 750mm(L) × 100mm(W) × 125mm(H)
- Cushioning: Adjustable air cushion (both ends)
- Protection rating: IP54 (standard), IP67 optional
- Piston rod material: Chrome-plated carbon steel
Heavy-duty locking cylinder featuring fail-safe position retention during air/power loss. The wedge-lock mechanism provides 360° radial holding force, ideal for vertical applications requiring mid-stroke stoppage. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
Typical Applications:
- Automated welding fixture position locking
- Elevator emergency braking systems
- Press machine intermediate position hold
- Material handling vertical load suspension
- Robotic arm pivot point stabilization
Installation note:
Requires minimum 0.3MPa unlocking pressure. Lubricate lock mechanism with ISO VG32 hydraulic oil monthly.
Avoid lateral forces exceeding 30N on piston rod during operation.
| Property | Property Value |
|---|---|
| sku | SCLF63X550 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 550mm |
| Lock Position | Front Cover with Lock |
