Airtac SCLF Front Locking Cylinder SCLF80X120
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X120 Front Lock Cylinder Technical Details
- Model: SCLF80X120
- Type: Double-acting with mechanical lock mechanism
- Bore size: Ø80mm (±0.1mm tolerance)
- Stroke: 120mm (adjustable ±2mm)
- Operating pressure: 0.1–1.0 MPa
- Lock holding force: 3,200N (at 0.5MPa)
- Lock release pressure: ≥0.3MPa
- Port thread: G1/2 (ISO228 standard)
- Cushioning: Adjustable hydraulic buffer
- Piston speed: 50–800mm/s
- Ambient temperature: -20℃ to +80℃
- Seal material: Nitrile Butadiene Rubber (NBR)
- Protection class: IP65 (dust-tight & water jet resistant)
- Weight: 5.8kg ±2% (excluding accessories)
- Dimensions: 320mm(L) × 95mm(W) × 95mm(H)
Heavy-duty locking cylinder with precision ground stainless steel guide rod and anti-rotation design. Features dual-position memory lock that engages automatically at stroke ends. Requires ISO VG32 hydraulic oil lubrication for optimal lock mechanism performance. Includes wear-resistant brass bushing for smooth operation under side loads.
- Press machine safety interlocks
- Automated welding fixture position retention
- Elevator emergency braking systems
- Die-casting mold clamping mechanisms
- Material handling vertical load stabilization
Installation protocol:
Mount using M10x1.5 grade 8.8 bolts with 25Nm torque.
Maintain 0.5mm minimum clearance between lock collar and mating surface.
Perform lock calibration after every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | SCLF80X120 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 120mm |
| Lock Position | Front Cover with Lock |
