Airtac SCLF Front Locking Cylinder SCLF80X125
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X125 Front Locking Cylinder Specifications
- Model: SCLF80X125
- Type: Double-acting cylinder with mechanical front lock
- Bore size: 80mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Locking force: 2,450 N (at 0.5 MPa)
- Cushioning: Adjustable pneumatic cushion
- Lock mechanism: Spring-activated wedge system
- Mounting type: Standard ISO/VDMA front flange (alternative mounts available)
- Port size: G1/2
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Piston rod material: Chrome-plated steel (STD) / Stainless steel (optional)
- Seal material: NBR (standard) / Polyurethane (high-speed variant)
- Weight: 3.8 kg (without accessories)
- Dimensions: 284mm(L) × 105mm(W) × 105mm(H) (at fully retracted position)
Heavy-duty locking cylinder featuring fail-safe position retention during air supply interruption. Precision-ground rod with triple chrome plating ensures ≤0.01mm radial play. Integrated shock absorbers reduce end-impact noise by 15dB. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Vertical load holding in automated assembly lines
- Safety positioning in press brake tooling
- Pallet locking in CNC machining centers
- Emergency stop systems for material handling robots
- Precision fixturing in optical component manufacturing
Installation note:
Engage lock mechanism manually after installation using the override lever.
Maintain 0.5mm minimum clearance between rod end and workpiece.
Lubricate guide bushings every 500km of cumulative travel.
Critical parameters:
Maximum side load 150N | Do NOT use as mechanical brake |
Cycle rate ≤90% of calculated maximum (derate 15% for vertical applications)
| Property | Property Value |
|---|---|
| sku | SCLF80X125 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
