Airtac SCLF Front Locking Cylinder SCLF80X150
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF Series Front Lock Cylinder SCLF80X150 Technical Details
- Model: SCLF80X150
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: Ø80 mm
- Stroke: 150 mm
- Operating pressure: 0.1–0.9 MPa
- Locking force: 2,800 N (at 0.5 MPa)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Standard ISO/VDMA flange (MF1/MF2 options)
- Port size: G1/2 (BSPP thread)
- Rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Ambient temperature: -20℃ to +80℃
- Weight: 5.8 kg (excluding accessories)
- Dimensions:
- Body length: 280 mm (excluding rod)
- Total stroke length: 430 mm
- Flange width: 125 mm
- Mounting height: 105 mm
- Protection class: IP54 (standard)
Heavy-duty locking cylinder featuring dual-position mechanical brake system with automatic wear compensation. The integrated wedge-lock mechanism provides secure mid-stroke position holding without pressure maintenance. Optimized for vertical applications requiring load suspension safety.
- Automated material handling systems
- Press machine safety interlocks
- Elevator positioning in cleanroom environments
- Robotic welding fixture clamping
- Overhead crane emergency stop systems
Installation guidelines:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Locking mechanism activates only when piston speed ≤50 mm/s.
Avoid side-load forces exceeding 10% of maximum thrust.
Critical note:
Always engage manual release lever during maintenance.
Locking function disabled without air pressure - implement mechanical safety backups.
| Property | Property Value |
|---|---|
| sku | SCLF80X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
