Airtac SCLF Front Locking Cylinder SCLF80X175
$130.96
Regular price
$138.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLF80X175
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking mechanism configurations: Front cover locking type and Rear cover locking type;
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
Installation requirements:
Maintain horizontal orientation for optimal locking performance.
Allow minimum 50mm clearance around cylinder body for heat dissipation.
Lock engagement requires 1-second pressure stabilization before loading.
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X175 Front Lock Cylinder Technical Details
- Model: SCLF80X175
- Type: Double-acting cylinder with mechanical lock
- Bore size: 80mm
- Stroke: 175mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,600N (at 0.5MPa)
- Port size: G1/2 (NPT1/2 optional)
- Cushioning type: Adjustable elastic cushion
- Temperature range: -10℃ to 70℃
- Body material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR/PU
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 4.8kg ±2%
- Dimensions: 374mm(L) × 80mm(Bore) × 95mm(H)
- Mounting type: Basic front flange (ISO 15552 standard)
- Lock release pressure: ≥0.3MPa
Heavy-duty locking cylinder featuring fail-safe mechanical position retention. The integrated wedge-lock mechanism prevents unintended movement during power loss, with precision ground rod for smooth operation. Requires 5μm filtered air and regular lubrication (ISO VG32 equivalent).
Industrial Applications:
- Press machine safety clamps
- Automated welding fixture positioning
- Elevator emergency braking systems
- Die-casting mold locking mechanisms
- Material handling vertical load stabilization
Installation requirements:
Maintain horizontal orientation for optimal locking performance.
Allow minimum 50mm clearance around cylinder body for heat dissipation.
Lock engagement requires 1-second pressure stabilization before loading.
| Property | Property Value |
|---|---|
| sku | SCLF80X175 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 175mm |
| Lock Position | Front Cover with Lock |
