Airtac SCLF Front Locking Cylinder SCLF80X50
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X50 Front Lock Cylinder Technical Specifications
- Model: SCLF80X50
- Type: Double-acting cylinder with mechanical lock
- Bore size: 80mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting types: MF1 (front flange), MB1 (rear pivot)
- Port size: G1/2 (ISO228/1 standard)
- Rod thread: M20×1.5 external
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Lock holding force: 2,500N (at 0.5MPa)
- Weight: 5.2kg (excluding accessories)
- Dimensions: 300mm(L) × 105mm(W) × 105mm(H) (extended length)
- Retracted length: 250mm
- ISO standard: 15552 (formerly ISO6431)
Heavy-duty lock cylinder with integrated mechanical braking system, featuring dual-position locking capability for mid-stroke position holding. The chrome-plated piston rod incorporates a special anti-rotation design, while the double-seal structure ensures zero leakage during static locking periods. Requires filtered air (≤5μm) with ISO VG32 lubricant.
- Vertical lifting mechanisms in assembly lines
- Safety locking in press machine tooling
- Position retention in material handling robots
- Overhead conveyor emergency stop systems
- Precision fixturing for CNC machining
Installation requirements:
Lock engagement requires minimum 0.3MPa air pressure. For vertical mounting,
install manual release lever (optional accessory AS-LK80) for maintenance.
Allow 50mm clearance behind cylinder for lock mechanism operation.
Maintenance note:
Relubricate every 500km of cumulative travel. Lock mechanism inspection
interval: 100,000 cycles or 12 months (whichever comes first). Never
disengage lock under load.
| Property | Property Value |
|---|---|
| sku | SCLF80X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
