Airtac SCLF Front Locking Cylinder SCLF80X75
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X75 Front Locking Cylinder Specifications
- Model: SCLF80X75
- Type: Double-acting pneumatic cylinder with mechanical front lock
- Bore size: 80mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Locking force: ≥5,000N (at 0.5MPa)
- Piston speed: 50–800mm/s
- Mounting style: MF1 front flange with ISO/VDMA mounting pattern
- Cushioning: Adjustable elastic cushion at both ends
- Rod material: Hard chrome-plated carbon steel (HRC 45-50)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (BSPP thread)
- Weight: 3.8kg (excluding accessories)
- Dimensions: 300mm(L) × 120mm(W) × 100mm(H) (extended length)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty locking cylinder featuring instant position-holding capability through its spring-engaged wedge locking mechanism. The dual piston design ensures stable locking even under sudden pressure loss. Includes wear-resistant guide rings and integrated magnetic sensor slots (M9 connector compatible). Requires 40μm filtered air with ISO VG32 lubrication recommended.
- Vertical load holding in material handling systems
- Emergency stop positioning in automotive fixtures
- Press brake tooling position retention
- Overhead conveyor safety brakes
- Plastic injection molding machine core pulls
Installation note:
Locking mechanism requires manual release via side access port during maintenance.
Avoid side loads exceeding 150N. For vertical mounting, install with rod facing downward
to prevent seal wear from piston self-weight.
| Property | Property Value |
|---|---|
| sku | SCLF80X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 75mm |
| Lock Position | Front Cover with Lock |
