Airtac SCLF Front Locking Cylinder SCLF80X80
$124.19
Regular price
$131.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCLF80X80
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking mechanism configurations: Front cover locking type and Rear cover locking type;
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
Installation criticals:
Must maintain ≤0.5° angular alignment during mounting. Lock engagement requires
minimum 0.3MPa pressure differential. Perform weekly lubrication checks in
high-cycle applications (>5,000 cycles/day).
Safety notice:
Always depressurize system before manual lock release. Do NOT use as
primary safety brake in vertical applications - requires secondary
mechanical backup.
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF80X80 Front Lock Cylinder Technical Specifications
- Model: SCLF80X80
- Type: Double-acting with mechanical lock
- Bore size: 80mm
- Stroke: Customizable (standard 80mm shown)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Locking force: 1,200N (at 0.5MPa)
- Port size: G1/2
- Mounting type: ISO 15552 standard flange
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 6.8kg (without accessories)
- Dimensions: 360mm(L) × 105mm(W) × 105mm(H) (at mid-stroke position)
- Protection rating: IP67 (wipers included)
- Lock release pressure: ≤0.15MPa
Heavy-duty locking cylinder featuring dual-position mechanical brake system with fail-safe mechanism. The integrated wedge-lock design maintains position during power loss, with precision ground guide rods ensuring ≤0.2mm repeatability. Requires ISO VG32 or equivalent lubrication.
Industrial Applications:
- Vertical lifting mechanisms in automotive assembly
- Position retention in CNC fixture systems
- Safety brakes for material handling robots
- Press machine intermediate stop positions
- Elevator emergency locking systems
Installation criticals:
Must maintain ≤0.5° angular alignment during mounting. Lock engagement requires
minimum 0.3MPa pressure differential. Perform weekly lubrication checks in
high-cycle applications (>5,000 cycles/day).
Safety notice:
Always depressurize system before manual lock release. Do NOT use as
primary safety brake in vertical applications - requires secondary
mechanical backup.
| Property | Property Value |
|---|---|
| sku | SCLF80X80 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 80 mm |
| Lock Position | Front Cover with Lock |
