Airtac SGD Series Steel Tube Type Double Rod Cylinder SGD160X175
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
AirTAC SGD Series Steel Tube Double Rod Cylinder SGD160X175 Technical Details
- Model: SGD160X175
- Type: ISO 15552 compliant double rod cylinder
- Bore size: Ø160mm (±0.5mm tolerance)
- Stroke: 175mm (customizable 25-2000mm)
- Operating pressure: 0.05-1.2MPa (7-174psi)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Standard ISO mounting (MF1/MF2/MF4 options)
- Port size: G1/2 (NPT1/2 optional)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Piston material: Extruded aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr12MoV, HRC≥45)
- Seals: HNBR/NBR/PU (optional FKM for high temp)
- Weight: 12.8kg (without accessories)
- Dimensions: 548mm(L) × 176mm(W) × 176mm(H) (at mid-stroke)
- Rod diameter: Ø35mm (dual rods)
- Protection rating: IP65 (standard wiper design)
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil)
Heavy-duty double rod cylinder featuring symmetrical force transmission and anti-rotation stability. The chrome-plated dual piston rods enhance lateral load capacity (up to 1,500N side force) while maintaining precise linear motion (±0.5mm repeatability). Integrated magnet slots allow for magnetic switch installation (SM/SMC series sensors compatible).
- Automotive welding fixture positioning systems
- Press machine die cushion mechanisms
- Glass tempering furnace door actuators
- Plastic injection molding ejectors
- Steel coil handling manipulators
Installation recommendation:
Use M12x1.75 grade 10.9 mounting bolts with Loctite 243.
Maintain 0.5mm alignment tolerance between rod ends and load.
For vertical mounting, install air vents upward.
| Property | Property Value |
|---|---|
| sku | SGD160X175 |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | 175mm |
