Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X100-50
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Pipe Adjustable Cylinder SGJ125X100-50 Technical Details
- Model Code: SGJ125X100-50
- Bore Size: 125mm (4.92")
- Stroke: 100mm ±0.5mm (3.94")
- Adjustable Stroke Range: 50-100mm (1.97"-3.94")
- Operating Pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Max Thrust: 1,470N @0.5 MPa
- Ambient Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable air cushion (both ends)
- Mounting Style: Basic type (Standard MF1)
- Port Size: G1/2 (BSPP)
- Tube Material: Cold drawn precision steel pipe
- Piston Rod: Hard chrome-plated carbon steel
- Seal Material: NBR (Nitrile Butadiene Rubber)
- Weight: 12.5kg (27.56 lbs)
- Dimensions:
- Length: 302mm (11.89") [Full retracted]
- Width: 144mm (5.67") [Flange to flange]
- Height: 144mm (5.67") [Cylinder OD]
- ISO Standard: 15552 compliant
- Lubrication: Pre-lubricated (Oil-free operation possible)
Heavy-duty adjustable stroke cylinder featuring precision-ground steel construction with wear-resistant chromium plating. The dual adjustable cushions minimize end-impact noise while the modular design allows stroke customization through spacer adjustment. Features integrated mounting threads and corrosion-resistant surface treatment (chromate plating + black oxide).
- Press machine stroke adjustment systems
- Automotive welding fixture positioning
- Die casting machine ejection mechanisms
- Packaging line height-adjustable stoppers
- Foundry equipment with variable clamping force
Installation Tip:
Use alignment jigs during mounting to ensure parallel piston rod movement.
For adjustable stroke applications, secure lock nuts with 25-30N·m torque after position setting.
Maintain 0.5mm minimum clearance between cushion screws and end caps.
| Property | Property Value |
|---|---|
| sku | SGJ125X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
