Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X1000-20
$525.52
Regular price
$533.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X1000-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation note:
Requires minimum 0.3mm/m alignment tolerance during mounting. For strokes over 800mm,
recommend using intermediate support brackets every 600mm. Lubricator oil viscosity:
ISO VG32 (32 cSt at 40℃). Max piston speed: 500mm/s.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Tube Adjustable Cylinder SGJ125X1000-20 Technical Details
- Model Code: SGJ125X1000-20
- Type: ISO 15552 compliant steel tube cylinder with adjustable cushioning
- Bore Size: 125mm (4.92")
- Stroke: 1000mm (39.37")
- Operating Pressure: 0.05-0.9 MPa (7-130 PSI)
- Port Size: G1/2 (ISO 228/1 standard)
- Cushion Type: Adjustable pneumatic cushion (both ends)
- Tube Material: Cold drawn precision steel tube (chrome-plated inner surface)
- Piston Rod: Hardened stainless steel (Cr Content≥13%)
- Rod Diameter: 40mm (1.57")
- Operating Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Weight: 32.5kg (71.65 lbs) ±2%
- Dimensions: 1600mm(L) × 205mm(W) × 205mm(H) (63"×8.07"×8.07")
- Mounting Options: Basic type (axial mounting) / Fixed type (front flange) / MS2 mounting standard
- Lubrication: Pre-lubricated (relubrication interval: 2000km stroke)
Industrial-grade heavy-duty cylinder designed for long-stroke applications requiring precise speed control and high lateral load capacity. Features double-layer chrome plating on inner surface for extended service life (up to 5000km stroke under standard conditions). Integrated magnetic piston version available (add "-M" suffix).
Typical Applications:
- Automated production line material handling systems
- Automotive welding fixture positioning
- Packaging machinery ejection mechanisms
- Plastic injection molding machine clamp units
- Steel coil handling equipment
Installation note:
Requires minimum 0.3mm/m alignment tolerance during mounting. For strokes over 800mm,
recommend using intermediate support brackets every 600mm. Lubricator oil viscosity:
ISO VG32 (32 cSt at 40℃). Max piston speed: 500mm/s.
| Property | Property Value |
|---|---|
| sku | SGJ125X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
