Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X1000-30
$525.52
Regular price
$533.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X1000-30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm. For vertical installations,
use auxiliary guide mechanisms when handling asymmetric loads. Lubricator unit
(AL-06 or equivalent) recommended for dry air systems.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ125X1000-30 Steel Pipe Adjustable Cylinder Specifications
- Model: SGJ125X1000-30
- Type: Steel pipe-guided adjustable stroke cylinder
- Bore size: Ø125mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Front flange (MF1) standard
- Operating temperature: -20℃ to 80℃
- Port size: G1/2 (ISO228/1 standard)
- Tube material: Cold drawn precision steel pipe (STKM13A)
- Piston rod material: Chrome-plated carbon steel (SUJ2)
- Seal material: NBR/PU combination
- Weight: 24.7kg (excluding accessories)
- Dimensions: 1135mm(L) × 160mm(W) × 160mm(H)
- Rod end thread: M30×1.5
- Max theoretical thrust: 1570N @0.5MPa
Heavy-duty industrial cylinder featuring precision-ground steel construction for extended stroke applications. The dual adjustable pneumatic cushioning system minimizes impact at stroke ends, while the chromium-plated piston rod provides exceptional corrosion resistance. Requires filtered air (40μm) with lubrication (ISO VG32 or equivalent).
Typical Applications:
- Automated assembly line positioning systems
- Large-scale material handling equipment
- Automotive welding fixture actuation
- Paper converting machinery
- Heavy press ejection mechanisms
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm. For vertical installations,
use auxiliary guide mechanisms when handling asymmetric loads. Lubricator unit
(AL-06 or equivalent) recommended for dry air systems.
Service Interval:
- Relubricate every 500km of cumulative travel
- Inspect rod seals every 3 million cycles
- Replace cushion seals every 5,000 operating hours
| Property | Property Value |
|---|---|
| sku | SGJ125X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
