Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X125-40
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Steel Tube Adjustable Cylinder SGJ125X125-40 Technical Details
- Model: SGJ125X125-40
- Type: Double-acting adjustable cushion cylinder (steel tube construction)
- Bore size: 125mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: G1/2 (BSPP thread)
- Piston rod material: Chrome-plated 45# steel
- Tube material: Cold drawn precision steel tube (surface anodized)
- Seal material: NBR + PU combination
- Weight: 12.8kg (without accessories)
- Dimensions:
- Extended length: 430mm
- Retracted length: 305mm
- Mounting base: 160mm × 160mm
- Rod end thread: M39×1.5
- ISO standard: 15552 (VDMA 24562)
- Protection rating: IP65 (standard wiper design)
Heavy-duty steel cylinder with precision-machined components, featuring external cushion adjustment screws for smooth motion control. The wear-resistant chromium plating and triple-lip wiper seal ensure extended service life in high particulate environments. Requires 40μm filtered air with recommended lubrication (ISO VG32).
- Automotive welding fixture clamping
- Foundry equipment door actuation
- Paper roll handling systems
- Injection molding machine ejectors
- Shipbuilding positioning mechanisms
Installation guidelines:
Mount using ISO 15552 standard brackets (MF1/MF2 patterns recommended).
Allow minimum 25mm lateral clearance for cushion adjustment.
Lubricate through air supply (oil mist) for initial 500km operation.
| Property | Property Value |
|---|---|
| sku | SGJ125X125-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 125mm |
